ABB CI858K01 3BSE018135R1 与过程PLC集成报警处理
Panel 800是一款用户友好、直观且符合人体工程学的操作员
将纤薄、节省空间的尺寸与
全面的高级功能。
所有面板都配备了用于
过程和设备控制，通过位于屏幕旁边的功能键或触摸LCD进行操作
陈列Panel 800结合了市场领先的性能和令人惊叹的图形功能，侵蚀了两者之间的界限
普通操作面板和基于PC的HMI。面板800为
工艺面板之后的继任者。
Panel 800是专门为ABB控制网络设计的
和AC 800M控制器，但得益于广泛的驱动器
面板800 5.1
库，Panel 800与大多数型号的PLC兼容
以及ABB传统控制系统。与一起使用时
AC 800M，某些独特功能可用，例如
与过程PLC集成报警处理。
面板800由现代强大的硬件平台组成，
这使得能够实现非常有限的安装深度。框架是
由粉末涂层铝制成，使面板具有
坚固的外观和感觉。前外壳设计用于
根据IP66标准，可承受苛刻的工业使用
标准这些面板还通过了DNV和UL的认证
Compact Control Builder是一个强大的工具，用于创建
控制解决方案和可重复使用的控制库
AC 800M过程PLC。
这一切都是在基于Windows的环境中完成的，提供
为ABB的工业提供广泛的控制功能
交流800米。从二进制逻辑到高级调节控制，
从离散过程信号到高级过程对象。
在不少于六种编程语言的任何选择中，
以最适合手头任务的为准。这些
分别是：指令列表、结构化文本、功能框图、，
顺序功能图、梯形图和控制
模块，后者是ABB自己对更高
应用工程效率和易用性。
Compact Control Builder产品包还包括
一个AC 800M OPC服务器和一个软控制器，用于测试
应用程序。
Panel 800 is a user-friendly, intuitive and ergonomic operator
panel that combines slim, space saving dimensions with a
comprehensive range of advanced functions.
All panels are equipped with advanced functionality for
process and equipment control, maneuvered either by function keys located next to the screen or by touching the LCD
display. Combined with market leading performance and stunning graphical ability, the Panel 800 erodes the line between
ordinary Operator Panels and PC based HMIs. Panel 800 is
the successor after the Process Panels.
Panel 800 is designed specifically for ABB Control Network
and AC 800M controllers, but thanks to the extensive driver
Panel 800 5.1
library, the Panel 800 is compatible with most makes of PLC
and ABB legacy control systems. When using it together with
AC 800M, certain unique features become available, such as
integrated alarm handling with the process PLCs.
Panel 800 consists of a modern powerful hardware platform,
which enables a very limited mounting depth. The frame is
made of powder-coated aluminum, giving the panels a very
robust look-and-feel. The front enclosure is designed to
withstand demanding industrious usage according to the IP66
standard. The panels have also been certified by DNV and UL
The Compact Control Builder, is a powerful tool for creating
control solutions and reusable control libraries for the
AC 800M process PLC.
It is all done in a Windows-based environment, offering
a wide range of control functionality for ABB’s industrial
AC 800M. From binary logic to advanced regulatory control,
from discrete process signals to high-level process objects.
In any choice of no less than six programming languages,
whichever are the most suitable for the tasks at hand. These
are: Instruction List, Structured Text, Function Block Diagram,
Sequential Function Chart, Ladder Diagram, and Control
Modules, the latter being ABB’s own contribution to higher
application engineering efficiency and ease of use.
The Compact Control Builder product package also includes
an AC 800M OPC-server and a soft-controller for testing of
the applications.
